Product Summary
The 1PS193-115 is a Schottky barrier diode. Application areas of the 1PS193-115 include Ultra high-speed switching, High frequency applications.
Parametrics
1PS193-115 absolute maximum ratings: (1)continuous reverse voltage: 40 V; (2)continuous forward current: 20 mA; (3)storage temperature: -65 +150 °C; (4)junction temperature: 150 °C.
Features
1PS193-115 features: (1)Ultra high switching speed; (2)Very low capacitance; (3)High breakdown voltage; (4)Leadless ultra small plastic package(1 mm 0.6 mm 0.5 mm); (5)Boardspace 1.17 mm2 (approx. 10% of SOT23); (6)Power dissipation comparable to SOT23.
Diagrams
 |
