Product Summary

The CXD1465R is an over sampling digital filter LSI.

Parametrics

CXD1465R absolute maximum ratings: (1)Supply voltage Vqd: -0.5 to +6.5 V; (2)Input voltage Vi: -0.5 to VDD +0.5 V; (3)Storage temperature Tstg: -55 to +150 °C; (4)Allowable power Pd: 450(Ta=75°C)mW.


Features

CXD1465R features: (1)83rd and 21st order filters linked through cascade connections provide a quadrupled sampling digital filter; (2)Built-in filters for 2 channels corresponding to L and R; (3)Variety of functions including soft-muting and offset addition; (4)83rd and 21st order filters also have 2 modes of filter coefficients each, to enable the selection of the most suitable filter characteristics, required for usage.

Diagrams

CXD1465R pin connection
