Product Summary

The FGH40N60SFDTU is a Field Stop IGBT using Novel Field Stop IGBT Technology. It offers the optimum performance for Induction Heating, UPS, SMPS and PFC applications where low conduction and switching losses are essential.

Parametrics

FGH40N60SFDTU absolute maximum ratings: (1)VCES, Collector to Emitter Voltage: 600 V; (2)VGES, Gate to Emitter Voltage: ± 20 V; (3)IC: Collector Current @ TC = 25℃: 80 A; Collector Current @ TC = 100℃: 40 A; (4)ICM, Pulsed Collector Current @ TC = 25℃: 120 A; (5)PD: Maximum Power Dissipation @ TC = 25℃: 290 W; Maximum Power Dissipation @ TC = 100℃: 116W; (6)TJ, Operating Junction Temperature: -55 to +150 ℃; (7)Tstg, Storage Temperature Range: -55 to +150 ℃; (8) TL, Maximum Lead Temp. for soldering Purposes, 1/8” from case for 5 seconds: 300 ℃.

Features

FGH40N60SFDTU features: (1) High current capability; (2) Low saturation voltage: VCE (sat) =2.3V @ IC = 40A; (3) High input impedance; (4) Fast switching; (5) RoHS compliant.

Diagrams

FGH40N60SFDTU block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
FGH40N60SFDTU
FGH40N60SFDTU

Fairchild Semiconductor

IGBT Transistors 600V 40A Field Stop

Data Sheet

0-1: $2.71
1-25: $2.42
25-100: $1.98
100-250: $1.79
Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
FGH40N120ANTU
FGH40N120ANTU

Fairchild Semiconductor

IGBT Transistors 1200V NPT

Data Sheet

0-1: $6.69
1-25: $6.08
25-100: $5.49
100-250: $5.05
FGH40N60SF
FGH40N60SF

Other


Data Sheet

Negotiable
FGH40N60SFDTU
FGH40N60SFDTU

Fairchild Semiconductor

IGBT Transistors 600V 40A Field Stop

Data Sheet

0-1: $2.71
1-25: $2.42
25-100: $1.98
100-250: $1.79
FGH40N60SFTU
FGH40N60SFTU

Fairchild Semiconductor

IGBT Transistors N-CH / 40A 600V FS Planar

Data Sheet

0-1: $2.77
1-25: $2.23
25-100: $2.03
100-250: $1.83
FGH40N60SMD
FGH40N60SMD

Fairchild Semiconductor

IGBT Transistors 600V, 40A Field Stop IGBT

Data Sheet

0-1: $2.79
1-25: $2.51
25-100: $2.29
100-250: $2.06
FGH40N60SMDF
FGH40N60SMDF

Fairchild Semiconductor

IGBT Transistors 600V/40A Field Stop IGBT ver. 2

Data Sheet

0-1: $2.47
1-25: $2.23
25-100: $2.03
100-250: $1.83
