Product Summary
The FGL40N120AND is an NPT IGBT. Employing NPT technology, FGL40N120AND of IGBTs provides low conduction and switching losses. The FGL40N120AND offers a solution for application such as induction heating (IH), motor control, general purpose inverters and uninterruptible power supplies (UPS). The applications of the FGL40N120AND include Induction Heating, UPS, AC & DC motor controls and general purpose inverters.
Parametrics
FGL40N120AND absolute maximum ratings: (1)Collector-Emitter Voltage, VCES: 1200V; (2)Gate-Emitter Voltage, VGES: ±25V; (3)Collector Current @TC = 25℃, IC: 64A; (4)Collector Current @TC = 100℃, IC: 40A; (5)Pulsed Collector Current, ICM: 160A; (6)Diode Continuous Forward Current @TC = 100℃, IF: 40A; (7)Diode Maximum Forward Current, IFM: 240A; (8)Maximum Power Dissipation @TC = 25℃, PD: 500W; (9)Maximum Power Dissipation @TC = 100℃, PD: 200W; (10)Short Circuit Withstand Time, VCE = 600V, VGE = 15V, TC = 125℃, SCWT: 10μs; (11)Operating Junction Temperature, TJ: -55 to +150℃; (12)Storage Temperature Range, TSTG: -55 to +150℃.
Features
FGL40N120AND features: (1) High speed switching; (2) Low saturation voltage: VCE (sat) = 2.6 V @ IC = 40A; (3) High input impedance; (4) CO-PAK, IGBT with FRD: trr = 75ns (typ.).
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 FGL40N120AND |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||||
 |
FGL40N120ANDTU |
Fairchild Semiconductor |
IGBT Transistors 1200V NPT IGBT |
Data Sheet |
|
|
||||||||||||
