Product Summary

The LMV324MTX is a low voltage (2.7–5.5V) dual and quad commodity op amp, which currently operates at 5–30V. The LMV324MTX is the most cost effective solution for the applications where low voltage operation, space saving and low price are needed. They offer specifications that meet or exceed the familiar LM358/324. The LMV324MTX has rail-to-rail output swing capability and the input common-mode voltage range includes ground. They all exhibit excellent speed-power ratio, achieving 1MHz of bandwidth and 1V/μs of slew rate with low supply current.

Parametrics

LMV324MTX absolute maximum ratings: (1)Machine Model: 100V; (2)Human Body Model: 2000V; (3)Differential Input Voltage: ± Supply Voltage; (4)Supply Voltage (V+–V-) 5.5V; (5)Output Short Circuit to V +; (6)Output Short Circuit to V -; (7)Soldering Information: Infrared or Convection (20 sec): 235℃; (8)Storage Temp. Range: -65℃ to 150℃; (9)Junction Temperature: 150 ℃.

Features

LMV324MTX features: (1)Guaranteed 2.7V and 5V Performance; (2)No Crossover Distortion; (3)Space Saving Package SC70-5 2.0x2.1x1.0mm; (4)Industrial Temp. Range -40℃ to +85℃; (5)Gain-Bandwidth Product 1MHz; (6)Low Supply Current: 410μA; (7)Rail-to-Rail Output Swing @ 10kΩ: V+ -10mV, V- +65mV; (8)VCM: -0.2V to V+-0.8V.

Diagrams

LMV324MTX connection diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
LMV324MTX
LMV324MTX
National Semiconductor (TI)
Operational Amplifiers - Op Amps
Data Sheet
0-2500: $0.31
2500-5000: $0.30
5000-10000: $0.28
LMV324MTX/NOPB
LMV324MTX/NOPB
National Semiconductor (TI)
Operational Amplifiers - Op Amps
Data Sheet
0-1: $0.85
1-25: $0.67
25-100: $0.59
100-250: $0.52
