Product Summary
IC TXRX RS485/422 250KBPS 8-SOIC
Category Integrated Circuits (ICs)
Family Interface - Drivers, Receivers, Transceivers
Series -
Type Transceiver
Number of Drivers/Receivers 1/1
Protocol RS422, RS485
Voltage - Supply 3 V ~ 3.6 V
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154", 3.90mm Width)
Supplier Device Package 8-SOIC
Packaging Tube
Parametrics
The MAX3483, MAX3485, MAX3486, MAX3488,
MAX3490, and MAX3491 are 3.3V, low-power trans-
ceivers for RS-485 and RS-422 communication. Each
part contains one driver and one receiver. The
MAX3483 and MAX3488 feature slew-rate-limited dri-
vers that minimize EMI and reduce reflections caused
by improperly terminated cables, allowing error-free
data transmission at data rates up to 250kbps. The par-
tially slew-rate-limited MAX3486 transmits up to
2.5Mbps. The MAX3485, MAX3490, and MAX3491
transmit at up to 10Mbps.
Features
Operate from a Single 3.3V Supply—
No Charge Pump!
Interoperable with +5V Logic
8ns Max Skew (MAX3485/MAX3490/MAX3491)
Slew-Rate Limited for Errorless Data Transmission
(MAX3483/MAX3488)
2nA Low-Current Shutdown Mode
(MAX3483/MAX3485/MAX3486/MAX3491)
-7V to +12V Common-Mode Input Voltage Range
Allows up to 32 Transceivers on the Bus
Full-Duplex and Half-Duplex Versions Available
Industry Standard 75176 Pinout
(MAX3483/MAX3485/MAX3486)
Current-Limiting and Thermal Shutdown for
Driver Overload Protection
Diagrams
<IMG src="http://www.seekic.com/uploadfile/ic-mfg/2012722225426462.jpg" border=0>
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 MAX3483ESA+T |
Maxim Integrated Products |
RS-422/RS-485 Interface IC 3.3V 10Mbps Transceiver |
Data Sheet |
|
|
||||||||||||
