Product Summary

The MAX547BCMH is a Voltage-Output DAC with Parallel Interface. Application areas of the MAX547BCMH include automatic test equipment, minimum component-count analog systems.

Parametrics

MAX547BCMH absolute maximum ratings: (1)VDD to GND ：-0.3V to +6V; (2)VSS to GND：-6V to +0.3V; (3)Digital Input Voltage to GND：-0.3V to (VDD + 0.3V); (4)REF：(AGND_ - 0.3V) to (VDD + 0.3V); (5)AGND：(VSS - 0.3V) to (VDD + 0.3V); (6)Maximum Current into REF_ Pin ：±10mA; (7)Maximum Current into Any Other Signal Pin ：±50mA.

Features

MAX547BCMH features: (1)Full 13-Bit Performance without Adjustments; (2)8 DACs in One Package; (3)Buffered Voltage Outputs; (4)Calibrated Linearity; (5)Guaranteed Monotonic to 13 Bits; (6)±5V Supply Operation; (7)Unipolar or Bipolar Outputs Swing to ±4.5V.

Diagrams

MAX547BCMH block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
MAX547BCMH-T
MAX547BCMH-T
Maxim Integrated Products
DAC (D/A Converters)
Data Sheet
Negotiable
MAX547BCMH+TD
MAX547BCMH+TD
Maxim Integrated Products
DAC (D/A Converters) 13-Bit 8Ch Precision DAC
Data Sheet
0-258: $30.87
258-500: $23.48
MAX547BCMH+T
MAX547BCMH+T
Maxim Integrated Products
DAC (D/A Converters) 13-Bit 8Ch Precision DAC
Data Sheet
0-318: $25.10
318-500: $21.35
MAX547BCMH+D
MAX547BCMH+D
Maxim Integrated Products
DAC (D/A Converters) 13-Bit 8Ch Precision DAC
Data Sheet
0-55: $27.89
55-100: $23.42
MAX547BCMH+
MAX547BCMH+
Maxim Integrated Products
DAC (D/A Converters) 13-Bit 8Ch Precision DAC
Data Sheet
0-50: $31.00
50-100: $22.96
MAX547BCMH
MAX547BCMH
Maxim Integrated Products
DAC (D/A Converters)
Data Sheet
Negotiable
