The MC3417L is a GaAs MMIC Low Noise Amplifier (LNA) which covers the frequency range of 24 to 30 GHz. The MC3417L can easily be integrated into Multi-Chip Modules (MCMs) due to its small (1.51 mm2) size. The MC3417L utilizes a GaAs PHEMT process offering 13 dB gain from a single bias supply of + 3V @ 30 mA with a noise fi gure of 2.5 dB. All data is with the MC3417L in a 50 ohm test fi xture connected via 0.025 mm (1 mil) diameter wire bonds of minimal length 0.31 mm (<12 mils).
Parametrics
MC3417L absolute maximum ratings: (1)Drain Bias Voltage (Vdd): +5.5 Vdc; (2)RF Input Power (RFIN)(Vdd = +3.0 Vdc): +3 dBm; (3)Channel Temperature: 175 ℃; (4)Continuous Pdiss (T = 85 ℃)(derate 3.44 mW/℃ above 85 ℃): 0.310 W; (5)Thermal Resistance (channel to die bottom): 290 ℃/W; (6)Storage Temperature: -65 to +150 ℃; (7)Operating Temperature: -55 to +85 ℃.
Features
MC3417L features: (1)Excellent Noise Figure: 2.5 dB; (2)Gain: 13 dB; (3)Single Supply: +3V @ 30 mA; (4)Small Size: 1.42 x 1.06 x 0.1 mm.
