Product Summary
The PC452 is a mini-flat package, darlinton phototransistor output, high collector-emitter voltage photocoupler. Its applications include telephone sets, copiers, facsimiles, interfaces wih various power supply circuits, power distribution boards.
Parametrics
PC452 absolute maximum ratings: (1)Forward current: 50mA; (2)reverse voltage: 6V; (3)power dissipation: 70mW; (4)collector-emitter voltage: 350V; (5)emitter-collector voltage: 0.1V; (6)collector current: 150mA.
Features
PC452 features: (1)Mini-flat package; (2)High collector-emitter voltage; (3)High current transfer ratio F = 1mA, V CE =2V); (4)High isolation voltage between input and output.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 PC452J00000F |
Sharp Microelectronics |
Transistor Output Optocouplers Photocoupler Darlington Output |
Data Sheet |
|
|
||||||
|
PC452TJ0000F |
Sharp Microelectronics |
Transistor Output Optocouplers Photocoupler Darlington Output |
Data Sheet |
|
|
||||||
 |
PC452 |
|
PHOTOCOUPLER HI VCE DARL 4-SMD |
Data Sheet |
Negotiable |
|
||||||
