AT24C16AN10SU27

Two-wire Serial EEPROM, 8-lead JEDEC SOIC, 5.0mA, -1.0V to +7.0V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.10~99.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.10~99.00

PartNumber:: AT24C16AN10SU27

Brand:: ATMEL Corporation - ATMEL | Pack: DIP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. David's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-07-20

From Other Seller

Part Number:AT24C16AN10SU27
US $0.10 - 99.00
ECA1HHG100

US $10.00 - 10.00 / Piece
(0) Remove
A50L-0001-0175

US $100.00 - 100.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AT24C16AN10SU27 is a Two-wire Serial EEPROM. The device provides 1024 bits of serial electrically erasable and programmable read-only memory (EEPROM) organized as 2048 words of 8 bits each. The AT24C16AN10SU27 is optimized for use in many industrial and commercial applications where low-power and low-voltage operation are essential. The AT24C16AN10SU27 is available in space-saving 8-lead JEDEC SOIC package and is accessed via a Two-wire serial interface. In addition, the entire family is available in 2.7V versions.

Parametrics

AT24C16AN10SU27 absolute maximum ratings: (1)Operating Temperature: –55℃ to +125℃; (2)Storage Temperature: –65℃ to +150℃; (3)Voltage on Any Pin with Respect to Ground: –1.0V to +7.0V; (4)Maximum Operating Voltage: 6.25V; (5)DC Output Current: 5.0 mA.

Features

AT24C16AN10SU27 features: (1)Low-voltage and Standard-voltage Operation: 2.7 (VCC = 2.7V to 5.5V), 1.8 (VCC = 1.8V to 5.5V); (2)Internally Organized 2048 x 8 (16K); (3)Two-wire Serial Interface; (4)Schmitt Trigger, Filtered Inputs for Noise Suppression; (5)Bidirectional Data Transfer Protocol; (6)100 kHz (1.8V) and 400 kHz (2.7V, 5V) Compatibility; (7)Write Protect Pin for Hardware Data Protection; (8)8-byte Page (1K, 2K), 16-byte Page (4K, 8K, 16K) Write Modes; (9)Partial Page Writes Allowed; (10)Self-timed Write Cycle (5 ms max); (11)High-reliability: Endurance: 1 Million Write Cycles, Data Retention: 100 Years; (12)Die Sales: Wafer Form, Waffle Pack and Bumped Wafers.
