DG202DJ

Quad SPST CMOS Analog Switch, DIP16, ±4.5V to ±18V, 20mA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~99.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~99.00

PartNumber:: DG202DJ

Brand:: Maxim Integrated Products - Maxim | Pack: DIP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. David's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-11-02

From Other Seller

Part Number:DG202DJ
US $1.00 - 99.00
YL-G709

US $65.00 - 68.00 / Piece
(0) Remove
iphone5 data cable

US $4.00 - 5.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The DG202DJ is a Quad SPST CMOS Analog Switch. It can be continuously operated with power supplies ranging from ±4.5V to ±18V. Maxim guarantees that the DG202DJ will not latch up if the power supplies are disconnected with input signals still connected. The device has guaranteed break-before-make switching, as well as essentially constant on-resistance over the analog signal range. The applications of the DG202DJ include: Analog Multiplexers, Programmable Gain Amplifiers, Communications Systems, Sample/Holds, Automatic Test Equipment, PBX, PABX.

Parametrics

DG202DJ absolute maximum ratings: (1)V+ to V-: 44V; (2)VIN to Ground: V-, V+; (3)VL to Ground: -0.3V, 25V; (4)VS or VD to V+: 0, -40V; (5)VS or VD to V-: 0, 40V; (6)V+ to Ground: 25V; (7)V- to Ground: -25V; (8)Current, Any Terminal Except S or D: 30mA; (9)Continuous Current, S or D: 20mA; (10)Peak Current, S or D(pulsed at 1ms 10% duty cycle max): 70mA; (11)Storage Temperature Range: -65℃ to +125℃.

Features

DG202DJ features: (1)Guaranteed ±4.5V to ±18V Operation; (2)No VL Supply Required; (3)Nonlatching with Supplies Turned Off and Input Signals Present; (4)CMOS and TTL Logic Compatible; (5)Monolithic, Low-Power CMOS Design.
