Product Summary

The F1CA024V is a power relay.

Parametrics

F1CA024V absolute maximum ratings: (1)Coil Power: 530 mW; (2)Coil Voltage: 24V; (3)Maximum Carrying Current: 7A; (4)Maximum Switching Rating: 1,250 VA / 120W; (5)Maximum Switching Voltage: 400 VAC / 300VDC; (6)Maximum Switching Load: 10mA 5 VDC; (7)Operating Temperature -40ºC to +75ºC.

Features

F1CA024V features: (1)Low profile power relay (height 16.5 mm)employing unique construction; (2)DPST/DPDT 5 A, TV-3 rating available; (3)Higher isolation by employing reinforced insulation co struction; (4)Insulation distance: 8 mm (between coiand contact); (5)Dielectric strength: 5 kV (between coiand contact); (6)Surge strength: 10 kV (between coiand contact); (7)Pin configuration compatible to VB/FBR620; (8)UL, CSA, VDE, SEMKO, SEV, CQC, FIMKO, IMQ, DEMKO, NEMKO recognized; (9)RoHS compliant since date code: 0434R Please see page 8 for more information.

Diagrams

F1CA024V pin connection
