Product Summary

The DAC7625U is a 12-bit quad voltage output digital-to-analog converter with guaranteed 12- bit monotonic performance over the specified temperature range. The DAC7625U accepts 12-bit parallel input data, have double-buffered DAC input logic (allowing simultaneous update of all DACs), and provide a readback mode of the internal input registers. The DAC7625U can operate from a single +5V supply or from +5V and –5V supplies.

Parametrics

DAC7625U absolute maximum ratings: (1)VDD to VSS: –0.3V to 11V; (2)VDD to GND: –0.3V to 5.5V; (3)VREFL to VSS: –0.3V to (VDD – VSS); (4)VDD to VREFH: –0.3V to (VDD – VSS); (5)VREFH to VREFL: –0.3V to (VDD – VSS); (6)Digital Input Voltage to GND: –0.3V to VDD + 0.3V; (7)Digital Output Voltage to GND: –0.3V to VDD + 0.3V; (8)Maximum Junction Temperature: +150℃; (9)Operating Temperature Range: –40℃ to +85℃; (10)Storage Temperature Range: –65℃ to +150℃; (11)Lead Temperature (soldering, 10s): +300℃.

Features

DAC7625U features: (1)low power: 20mw; (2)unipolar or bipolar operation; (3)settling time: 10ms to 0.012%; (4)12-bit linearity and monotonicity: –40℃ to +85℃; (5)reset to mid-scale (dac7624)or zero-scale (dac7625); (6)data readback; (7)double-buffered data inputs.

Diagrams

DAC7625U pin connection
