L78L05ABUTR

L78L05ABUTR, positive voltage regulator, SOT, 30V, 100mA, STMicroelectronics

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~99.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~99.00

PartNumber:: L78L05ABUTR

Brand:: STMicroelectronics - ST | Pack: SOT | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. David's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-11-29

From Other Seller

Part Number:L78L05ABUTR
US $1.00 - 99.00
TMS320C6414TBGLZA7

US $58.00 - 65.00 / Piece
(0) Remove
A50L-0001-0175

US $100.00 - 100.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The L78L05ABUTR is a positive voltage regulator. The L78L05ABUTR employ internal current limiting and thermal shutdown, making them essentially indestructible. If adequate heat-sink is provided, they can deliver up to 100 mA output current. They are intended as fixed voltage regulators in a wide range of applications including local or on-card regulation for elimination of noise and distribution problems associated with single-point regulation. In addition, they can be used with power pass elements to make high-current voltage regulators. The L78L05ABUTR used as Zener diode/resistor combination replacement, offers an effective output impedance improvement of typically two orders of magnitude, along with lower quiescent current and lower noise.

Parametrics

L78L05ABUTR absolute maximum ratings: (1) DC Input Voltage : 30V; (2) Output Current : 100mA; (3) Storage Temperature Range : -40 to +150℃; (4) Operating Junction Temperature Range : -40 to +125℃.

Features

L78L05ABUTR features: (1)Output current up to 100 mA; (2)Output voltages of 3.3; 5; 6; 8; 9; 10; 12; 15; 18; 20; 24V; (3)Thermal overload protection; (4)Short circuit protection; (5)No external components are required; (6)Available in either ±5% (AC) or ±10% (C) selection.
