PIC16F747-I/PT

28/40-pin, 8-bit CMOS FLASH Microcontroller, SOP28, 200 mA, -0.3 to +6.5V, High performance

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~99.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~99.00

PartNumber:: PIC16F747-I/PT

Brand:: Microchip Technology - Microchip | Pack: SMD | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. David's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-11-02

From Other Seller

Part Number:PIC16F747-I/PT
US $1.00 - 99.00
EKXG401ELL6R8MJ16S

US $5.00 - 5.00 / Piece
(0) Remove
ECA1HHG100

US $10.00 - 10.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The PIC16F747-I/PT is a 28/40-pin, 8-bit CMOS FLASH Microcontroller. It is available only in 28-pin packages.

Parametrics

PIC16F747-I/PT absolute maximum ratings: (1)Ambient temperature under bias: -55℃ to +125℃; (2)Storage temperature: -65℃ to +150℃; (3)Voltage on any pin with respect to VSS (except VDD and MCLR): -0.3V to (VDD + 0.3V); (4)Voltage on VDD with respect to VSS: -0.3 to +6.5V; (5)Voltage on MCLR with respect to VSS: 0 to +13.5V; (6)Total power dissipation: 1W; (7)Maximum current out of VSS pin: 300 mA; (8)Maximum current into VDD pin: 250 mA; (9)Input clamp current, IIK (VI < 0 or VI > VDD): ±20 mA; (10)Output clamp current, IOK (VO < 0 or VO > VDD): ±20 mA; (11)Maximum output current sunk by any I/O pin: 25 mA; (12)Maximum output current sourced by any I/O pin: 25 mA; (13)Maximum current sunk by PORTA: 200 mA; (14)Maximum current sourced by PORTA: 200 mA; (15)Maximum current sunk by PORTB: 200 mA; (16)Maximum current sourced by PORTB: 200 mA.

Features

PIC16F747-I/PT features: (1)High performance RISC CPU; (2)Only 35 single word instructions to learn; (3)All single cycle instructions except for program branches which are two-cycle; (4)Operating speed: DC - 20 MHz clock input; DC - 200 ns instruction cycle; (5)Up to 8K × 14 words of FLASH Program Memory, Up to 368 × 8 bytes of Data Memory (RAM); (6)Pinout compatible to the PIC16F873/874/876/877; (7)Interrupt capability (up to 12 sources); (8)Eight level deep hardware stack; (9)Direct, Indirect and Relative Addressing modes; (10)Processor read access to program memory.
